Proxmox VE 8: Windows 11 vGPU (VT-d) Passthrough with Intel Alder Lake

This post covers using an Intel 12th Gen (Alder Lake) CPU with Proxmox VE 8 to do VT-d vGPU passthrough to a Windows 11 Pro VM. This enables multiple VMs on the same Proxmox host share the GPU via virtual functions (VFs). What is VT-d vGPU and how is it different from ‘legacy’ GPU passthrough?

“Legacy” GPU passthrough requires that the entire GPU be dedicated to a single VM. Other VMs on the Proxmox host can NOT share the GPU. However, there is newer technology called Intel VT-d (Intel Virtualization Technology for Directed I/O) which is related to SR-IOV (Single Root I/O virtualization). This enables compatible devices to virtualize a device, like a GPU,  into multiple VFs (virtual functions). This enables, for instance, multiple VMs on a single Proxmox host to share the same physical GPU and benefit from hardware acceleration as if they had their own physical GPU.

The screenshot below is from my Beelink i5-1240P Proxmox VE 8 host. The “root” GPU is at PCIe 02.0, while there are 7 VF GPUs. This means I can have up to 7 VMs using the same physical GPU. Pretty cool right?

And as you can see in the screenshot below, Windows and the Intel drivers are none the wiser. It looks like a regular Intel UHD graphics card to Windows. And you install the regular Windows 11 Intel drivers, and they just magically work.

Update July 7, 2023: Windows 11 Pro continues to be rock solid with zero issues for several weeks of 24/7 usage. But take note that I’m not passing the Windows VM through to a physical HDMI port. I’m only accessing the Windows 11 VM via RDP. The Linux vGPU drivers have some issues. Namely, a Plex LXC doesn’t properly support HDR tone mapping. The video stream is corrupted. However, regular hardware transcoding works just fine.

So, if you want to host multiple Windows 11 VMs on your Proxmox server using vGPU, that should work just fine. If you want to use Linux based VMs or LXCs, do thorough testing to see if it works or not. It may not.

My Working Configuration

Now not all CPUs support VT-d/SR-IOV with their GPU. Intel only supports it on 11th Generation and later CPUs. It considers prior generations “legacy”. So what did I test and verify works?

  • Beelink Mini S12 Pro (Intel 12th Gen N100)
  • Beelink SEi12 Pro (Intel 12th Gen Core i5-1240P)
  • Proxmox VE 8.0
  • Windows 11 Pro (22H2)
  • Intel GPU Driver

You can read more about my Beelink servers here: Hands On: Beelink Mini-PCs for Proxmox, Home Assistant and Plex. From reading various posts on forums, it seems that Intel 11th Gen vGPU VFs have issues in Windows with the Intel drivers. It may work on Linux, but not Windows. There’s a nice thread on the Intel forums about it.

Proxmox VE 8 Host Prep

Note: At the Proxmox host BIOS level you must make sure that Intel VT-d is enabled.

  1. First we need to clone the Dynamic Kernel Module System (DKMS) repo and edit the config. In the Proxmox UI open a host shell (click on the Proxmox host, in the middle pane click on Shell). Run the following commands:
					apt-get install git
mkdir repo
cd repo
git clone
cd i915-sriov-dkms/


2. We need to modify the dkms.conf file to change the package name and package version.

					nano dkms.conf

3. Delete the first two lines of the file and then paste in the two lines below. Save and exit Nano.


4. Run the following commands

					cd ..
mv i915-sriov-dkms/ /usr/src/i915-sriov-dkms-6.1
apt update && apt install pve-headers-$(uname -r)
apt install git dkms build-* unzip -y


5. Run the following command to build and install DKMS.

					dkms install --force -m i915-sriov-dkms -v 6.1

6. Now let’s make sure DKMS status looks good.

					dkms status

7. We need to modify GRUB for vGPU SR-IOV. I am providing two GRUB configuration options. The first is for vGPU SR-IOV only. The second adds the needed parameters for a Google Coral PCIe TPU to be passed through to a VM. Comment out your existing GRUB_CMDLINE_LINUX_DEFAULT and then paste either the first or second line below.

What we need to add to Grub is: intel_iommu=on iommu=pt i915.enable_guc=3 i915.max_vfs=7

Note: The pasted line might look a little funny if it wraps the console window. Don’t worry. Save, exit, then open Nano again to verify it looks right. It should.

					nano /etc/default/grub

Use the line below if you are NOT using a Google Coral PCIe TPU:

					GRUB_CMDLINE_LINUX_DEFAULT="quiet intel_iommu=on iommu=pt i915.enable_guc=3 i915.max_vfs=7"

Use the line below if you ARE using a Google Coral PCIe TPU:

					GRUB_CMDLINE_LINUX_DEFAULT="quiet intel_iommu=on iommu=pt i915.enable_guc=3 i915.max_vfs=7 initcall_blacklist=sysfb_init pcie_aspm=off"

Below is a screenshot from a host that does NOT have a Google Coral PCIe TPU.

Note: If you are using ZFS (most aren’t), then the community suggested the following steps. DO NOT run the steps below if you aren’t using ZFS. I don’t use ZFS so haven’t tested them.

ZFS users ONLY

Append intel_iommu=on iommu=pt i915.enable_guc=3 i915.max_vfs=7 to /etc/kernel/cmdline then do update-initramfs -u -k all, followed by proxmox-boot-tool refresh

8. Update grub and install the sysfsutils.

update-initramfs -u
apt install sysfsutils -y

9. Now we need to find which PCIe bus the VGA card is on. It’s typically 00:02.0

					lspci | grep VGA

10. Run the following command and modify the PCIe bus number if needed. In this case I’m using 00:02.0.

					echo "devices/pci0000:00/0000:00:02.0/sriov_numvfs = 7" > /etc/sysfs.conf

11. Reboot the Proxmox host.
12. Login to the Proxmox host, open a Shell, then run the command below. It should return A LOT of data. If everything was successful, at the end you should see Enabled 7 VFs

					dmesg | grep i915

13. Now that the Proxmox host is ready, we can install and configure Windows 11 (22H2). If you do NOT see 7 VFs enabled, stop. Troubleshoot as needed. Do not pass go, do not collect $100 without 7 VFs.

Windows 11 Installation

Configuring Windows 11 for vGPU is a little finicky and could result in the Intel driver giving you a “Code 43” error and not working. In my example I’ll be using a password less Microsoft account, which creates complications to enable (and use) RDP. But it is possible, so I’ll walk you through the whole process.

  1. Upload your Windows 11 (22H2) ISO to the Proxmox server.
  2. Start the VM creation process. On the General tab enter the name of your VM. Click Next.
  3. On the OS tab select the Windows 11 22H2 ISO, and change the Guest OS as shown below to match. Click Next.

4. On the System page modify the settings to match EXACTLY as those shown below. If your local VM storage is named differently (e.g. NOT local-lvm, use that instead).

5. On the Disks tab, modify the Cache as shown and enable Discard (if you are using SSD/NVMe storage). I suggest at least 64GB disk size, as 32GB is super tight.

6. On the CPU tab, change the Type to host. Allocate however many cores you want.

7. On the Memory and Network tabs, configure as you wish. Leave the default Intel E1000 NIC. We will change it to VirtIO later.
8. Open a Proxmox console to the Windows VM. If the Windows installer doesn’t boot, “reset” the VM and press a key to start the installer.
9. Proceed through the Windows installation wizard, selecting the edition (I picked Windows 11 Pro), then Custom install. Wait for Windows to install and reboot.

Windows 11 Configuration

  1. Run through the Windows setup wizard. When you finally reach the desktop, proceed.
  2. Download the latest Windows VirtIO driver ISO. Upload it to the Proxmox host and mount it to the Windows VM. You can click on the graphic below to directly download the ISO from the official Fedora site, or click here.
Click on the graphic to download the latest VirtIO

3. In Windows open the mounted ISO in Explorer. Run virtio-win-gt-x64 and virtio-win-guest-tools. Use all default options. Reboot after they are both installed.

4. In the Proxmox UI review the Summary for the Windows VM and verify it lists one or more IPs. This means the QEMU agent is working.

5. Open a Proxmox console to the VM and login to Windows 11.
6. Click on the Windows icon in the start bar. Click on your account name in the lower left. Select Change Account Settings.
7. Click on Sign in with a local account instead.

8. Walk through the wizard and make note of your user name, then set a password and password hint. Write this information down!

9. Log back into the Windows VM via the Proxmox console.
10. In the search bar type remote desktop then click on Remote desktop settings.

11. Enable Remote Desktop.

12. Open your favorite RDP client and login using the user name and credentials you setup in Step 8. You should now see your Windows desktop and the Proxmox console window should show the lock screen.
13. Inside the Windows VM open your favorite browser and download the latest Intel “Recommended” graphics driver from here. In my case I’m grabbing
14. Shutdown the Windows VM.
15. In the Proxmox console click on the Windows 11 VM in the left pane. Then click on Hardware. Click on the Display item in the right pane. Click Edit, then change it to none.

Note: If in the next couple of steps the 7 GPU VFs aren’t listed, try rebooting your Proxmox host and see if they come back. The try adding one to your Windows VM again.

16. In the top of the right pane click on Add, then select PCI Device.
17. Select Raw Device. Then review all of the PCI devices available. Select one of the sub-function (.1, .2, etc..) graphics controllers (i.e. ANY entry except the 00:02.0). Do NOT use the root “0” device, for ANYTHING. I chose 02.1. Click Add. Do NOT tick the “All Functions” box. Tick the box next to Primary GPU.

18. Power on the Windows 11 VM and wait a couple of minutes for it to boot and RDP to become active. Note, the Proxmox Windows console will NOT connect since we removed the virtual VGA device. You will see a Failed to connect to server message. You can now ONLY access Windows via RDP.
19. RDP into the Windows 11 VM. Locate the Intel Graphics driver installer and run it. If all goes well, you will be presented with an Installation complete! screen. Reboot. If you run into issues with the Intel installer, skip down to my troubleshooting section below to see if any of those tips help.

20. RDP into Windows and launch Device Manager
21. Expand Display adapters and verify there’s an Intel adapter in a healthy state (e.g. no error 43).

22. You can also launch the Intel Graphics Command Center and view the GPU status.

23. If you wish to improve network performance, you can go back to the Proxmox console, and hot-swap the NIC to VirtIO (paravirtualized). The RDP session should reconnect after a few seconds.

24. I played a Youtube video in Edge and you can see the GPU being used.

Troubleshooting Intel Driver Installation

The first time I did this on my N100 Proxmox server the Intel drivers had issues installing. For some reason the RDP session would freeze mid way through the install, or would get disconnected and then fail to connect. I had to reboot the VM from the Proxmox UI and then re-start the Intel installer using their “clean” option. After a couple of re-installs, it ran just fine. It ran flawlessly the first time on my i5-1240P server. If after a VM reboot RDP can’t connect after a few minutes, reboot the VM and try again.


Getting Proxmox VE 8 to use VT-d for vGPU passthrough with Windows 11 Pro is a bit tedious, but I got it working on both of my Intel 12th Gen Alder Lake Beelink mini-PCs. Windows 11 Pro with the stock Intel GPU drivers uses the vGPU virtual function like a champ. By using virtual functions (VFs), you are able to share the Intel GPU with up to 7 other VMs on the Proxmox host. This is far better than legacy GPU passthrough where only a single VM could use the GPU. Make sure if you deploy additional VMs that need vGPU resources that you assign it a different vGPU VF. Do NOT assign the same PCIe device to two or more VMs.
